Howo 6x4 Tipper Truck

Howo 6x4 Tipper Truck

37500 USD

The sino tipper trucks for sale uses balance suspension, which can calmly cope with the severe challenges of complex road conditions.

SKU: TRUCK9409005
GTIN:
MPN: TRUCK9409005
Brand: Sinotruk

Sino trucks price: 37500 USD

Since the howo tipper truck can automatically tip over for unloading at a certain angle, sino tipper trucks for sale greatly saves unloading time and labor, shortens the transportation cycle, improves production efficiency, and reduces transportation costs.

The sino tipper trucks for sale uses balance suspension, which can calmly cope with the severe challenges of complex road conditions.

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia

Howo Tipper Truck | Sino Tipper Trucks for Sale Price in Namibia



Specification of howo tipper truck:

MODEL: ZZ3317N3567N1B

ENGINE: WD615.47, Euro II emission standard

CLUTCH: SINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance

TRANSMISSION: Transmission, model HW19710, 10 forward and 2 reverse  Ratio: 5.73

FRONT AXLE: New HF9 series, with drum brake system

REAR AXLE: HC16 pressed axle housing, single reduction and differential locks between axles; with drum brake system.

STEERING: ZF8118, hydraulic steering with power assistance  Ratio: 22.2-26.2:1

WHEELS&TYRES:

Rims: 8.5-20,10 hole-steel

Types: 13R22.5

CARGO BODY: 5600*2300*1500, bottom 8mm, side 6mm, Middle lift system (Other sizes are optional)

DIMENSIONS(in mm): 9745x2496x3550



Advantages of sino tipper trucks for sale:

For the front axle, howo tipper truck is equipped with the HR9 front axle, using a multi-leaf spring suspension of 9 steel plates, the front axle brake is disc brakes, and a protective cover is added to the entire braking system, which can effectively prevent splash to damage the brake disc and caliper.

The rear axle uses SINOTRUK AC16 model wheel-side reduction axle with automatic adjustment arm. The rear axle speed ratio is 4.77. The rear axle uses traditional drum brakes, which has stronger braking force. In addition, the rear axle is also equipped with a lateral stabilizer bar, It provides well guaranteed for driving stability when the vehicle is running on complex road conditions.
